Features
HIGH-PERFORMANCE BURNERS (12,000 to 18,000 BTUs)
Equipped with high-powered burners from 12,000 to 18,000 BTUs ensuring precise cooking results and even heat retention and distribution.
WHITE PROJECTOR LIGHT ON PANEL.
The panel is illuminated by a white projector light, ensuring easy visibility and a modern look.
COMMERCIAL CONVECTION FAN.
The oven broiler features a 10,000 BTU tube for quick and efficient broiling.
TELESCOPIC RACKS
Telescopic racks use ball bearing rack guides for an effortless glide in and out of the oven and adjusts to fit different rack support levels.
POWERFUL BROIL BURNER (10,000 BTU)
The oven broiler features a 10,000 BTU tube for quick and efficient broiling.
POWERFUL BROIL BURNER (22,000 BTU / 14,000 BTU)
The powerful bake burner provides 22,000 BTU (30” Oven) / 14,000 BTU (18” Oven) of consistent heat for even baking.
PANORAMIC VIEWING WINDOW.
Take a look inside the oven through the panoramic viewing window for a full, clear view of your dishes as they cook, allowing you to monitor progress without opening the door.
Specifications
General
Series Name
Gordon Ramsay
Fuel Type
Natural Gas
Installation Type
Freestanding
Color
Black
Manufacturer Color
Black with Bronze Accent
Cooktop
Burners/Elements
7
Burners/Elements Output
• (1) Front Left Burner 12,000 BTU
• (2) Front Center Burner 18,000 BTU
• (3) Front Right Burner 12,000 BTU
• (4) Rear Left Burner 12,000 BTU
• (5) Rear Center Burner 12,000 BTU
• (6) Rear Right Burner 12,000 BTU
• (7) Griddle Burner 15,000 BTU
• (2) Front Center Burner 18,000 BTU
• (3) Front Right Burner 12,000 BTU
• (4) Rear Left Burner 12,000 BTU
• (5) Rear Center Burner 12,000 BTU
• (6) Rear Right Burner 12,000 BTU
• (7) Griddle Burner 15,000 BTU
Burners
Sealed
Other
Griddle
Oven
Capacity (cu. ft.)
• Total Capacity: 7.0 cu. ft.
• Large Oven: 4.8 cu. ft.
• Small Oven: 2.2 cu. ft.
• Large Oven: 4.8 cu. ft.
• Small Oven: 2.2 cu. ft.
Number of Ovens
Double
Programs
• Bake
• Conv Bake
• Roast
• Conv Roast
• Broil
• Conv Bake
• Roast
• Conv Roast
• Broil
Features
Technologies
Commercial Convection Technology
Control Lock
Yes
Convection
Yes
Oven Light
Yes
Additional Information
Oven Control Features: Light On/ Off, Convection Fan On / Off Bake Burner (30" Oven): 22,000 BTU Broil Burner (30" Oven): 10,000 BTU Bake Burner (18" Oven): 14,000 BTU Baking Sheet Size: 30" Fits 29" x 16" Baking sheet, 18" Fits 16 x 12 1/2" Baking sheet
Electrical Information
Information
• 15 A
• 120 V
• 60 Hz
• Plug Type: US 3-prong
• 120 V
• 60 Hz
• Plug Type: US 3-prong
Accessories
Included
• 2 Standard Oven Rack
• 2 Telescopic rack
• 2 Broiler Pan Set
• 2 Telescopic rack
• 2 Broiler Pan Set
Optional
• Island Trim
• Reversible Cast Iron Griddle and Grill Plate RG1022
• Wok Ring WK01
• Reversible Cast Iron Griddle and Grill Plate RG1022
• Wok Ring WK01
Dimensions
Class Width
48"
Width
47.87 inch(es) / 121.6 cm
Height
40 inch(es) / 101.6 cm
Depth (Including Handles)
29 inch(es) / 73.66 cm
Weight
328 lb(s) / 148.78 kg
Additional Dimensions
• Oven Internal Width: 30" Oven: 23 3/4", 18" Oven: 12 5/8"
• Oven Internal Depth: 19 1/2"
• Oven Internal Height: 18"
• Rubber Spacer Depth (Install On Back Panel): 3/4"
• Product Height (From Bottom To Top Of Back Splash): 40"
• Product Height (From Bottom To Top Of Side Panel): 36"
• Product Depth (From Back Panel To Handle): 29"
• Product Depth (From Back Panel To Bullnose): 27 1/2"
• Product Depth (From Back Panel To Control Panel): 26 3/8"
• Product Depth (From Back Panel To Side Panel Front): 24"
• Cutout Dimensions (WxDxH): 48" x 24 3/4" x 36"- 37"
• Adjustable Height: 1" Max
• Oven Internal Depth: 19 1/2"
• Oven Internal Height: 18"
• Rubber Spacer Depth (Install On Back Panel): 3/4"
• Product Height (From Bottom To Top Of Back Splash): 40"
• Product Height (From Bottom To Top Of Side Panel): 36"
• Product Depth (From Back Panel To Handle): 29"
• Product Depth (From Back Panel To Bullnose): 27 1/2"
• Product Depth (From Back Panel To Control Panel): 26 3/8"
• Product Depth (From Back Panel To Side Panel Front): 24"
• Cutout Dimensions (WxDxH): 48" x 24 3/4" x 36"- 37"
• Adjustable Height: 1" Max
Shipping Dimensions
Width
51 inch(es) / 129.54 cm
Height
47.5 inch(es) / 120.65 cm
Depth
30 inch(es) / 76.2 cm
Weight
390 lb(s) / 176.9 kg
Warranty
Warranty
2 Years Parts and Labor
