Specifications
General
Fuel Type
Dual Fuel - Natural Gas
Installation Type
Freestanding
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Cooktop
Burners/Elements
6
Burners/Elements Output
• Front Left Sealed Single Burner BTU: 18,000
• Front Center Sealed Dual Burner BTU: 15,000
• Extra Low Simmer Function BTU: 650
• Front Right Sealed Single Burner BTU: 18,000
• Rear Left Sealed Single Burner BTU: 12,000
• Rear Center Sealed Single Burner BTU: 12,000
• Rear Right Sealed Dual Burner BTU: 15,000
• Extra Low Simmer Function BTU: 650
• Stainless Steel Griddle BTU: 15,000
• Front Center Sealed Dual Burner BTU: 15,000
• Extra Low Simmer Function BTU: 650
• Front Right Sealed Single Burner BTU: 18,000
• Rear Left Sealed Single Burner BTU: 12,000
• Rear Center Sealed Single Burner BTU: 12,000
• Rear Right Sealed Dual Burner BTU: 15,000
• Extra Low Simmer Function BTU: 650
• Stainless Steel Griddle BTU: 15,000
Burners
Sealed
Other
Griddle
Oven
Capacity (cu. ft.)
• Small oven: 2.5 cu.ft.
• Large oven: 4.2 cu.ft.
• Large oven: 4.2 cu.ft.
Number of Ovens
Double
Features
Technologies
Thermostatically Controlled Oven Heating System
Convection
Yes
Delay Bake/Start
No
Digital Temperature Display
No
Downdraft Ventilation
No
Oven Light
Yes
Self-Cleaning
No
Wi-Fi
No
Additional Information
• Bake Power 850 W(Top)
• 3,000 W (Bottom)
• Broil Power 3,500 W
• Black Porcelain Drip Pan On Cook Top
• Black Porcelain Oven Interior
• Thermostatically Controlled Griddle with Dishwasher Safe Drip Pan
• Heavy Duty Continuous Cast Iron Cooking Grates
• Automatic Re-Ignition Safety Feature
• Reverse Direction Commercial Convention Fan (30-inch Oven)
• Three (3) Halogen Oven Interior Lights
• CSA Certified Brass Burner Control Knobs
• CSA Certified Unit
• 3,000 W (Bottom)
• Broil Power 3,500 W
• Black Porcelain Drip Pan On Cook Top
• Black Porcelain Oven Interior
• Thermostatically Controlled Griddle with Dishwasher Safe Drip Pan
• Heavy Duty Continuous Cast Iron Cooking Grates
• Automatic Re-Ignition Safety Feature
• Reverse Direction Commercial Convention Fan (30-inch Oven)
• Three (3) Halogen Oven Interior Lights
• CSA Certified Brass Burner Control Knobs
• CSA Certified Unit
Electrical Information
Information
• 240 V
• 40 A
• 60 Hz
• 40 A
• 60 Hz
Accessories
Optional
• Stainless Steel Island Trim
• Liquid Propane Gas Conversion Kit
• High Altitude Conversion Kits for LP/Natural Gas
• Liquid Propane Gas Conversion Kit
• High Altitude Conversion Kits for LP/Natural Gas
Dimensions
Class Width
48"
Width
48 inch(es) / 121.92 cm
Height
38 inch(es) / 96.52 cm
Depth (Without Handles)
26 inch(es) / 66.04 cm
Weight
400.01 lb(s) / 181.44 kg
Additional Dimensions
Required Cutout Size (W x D x H) (in): 48" x 24"-25" x 35 ½"-36 ½"
Warranty
Warranty
2-Year parts and labor warranty
