Features
RADIANT BURNERS
Radiant burners use electric heating elements beneath a smooth, ceramic glass surface to deliver even and consistent heat.
WHITE PROJECTOR LIGHT ON PANEL.
The panel is illuminated by a white projector light, ensuring easy visibility and a modern look.
TRUE CONVECTION FAN.
For even heat distribution within the oven.
POWERFUL BROIL ELEMENT
The oven broiler features a 3,500 watts tube for quick and efficient broiling
Specifications
General
Series Name
Gordon Ramsay
Fuel Type
Electric
Installation Type
Freestanding
Color
Black
Manufacturer Color
Black with Black Accent
Cooktop
Burners/Elements
5
Burners/Elements Output
• (1) Front Left Element 3,000 W (1,500 W &1,500 W)
• (2) Front Right Element 3,000 W (1,800W &1,200 W)
• (3) Rear Left Element 1,200 W
• (4) Rear Center Element 100 W
• (5) Rear Right Element 1,200 W
• (2) Front Right Element 3,000 W (1,800W &1,200 W)
• (3) Rear Left Element 1,200 W
• (4) Rear Center Element 100 W
• (5) Rear Right Element 1,200 W
Elements
Smoothtop
Oven
Capacity (cu. ft.)
6.0 cu. ft.
Number of Ovens
Single
Programs
• Bake
• Conv Bake
• Roast
• Conv Roast
• Air Fry
• Pizza
• Proof
• Keep Warm
• Fast Preheat
• Dehydrate
• Conv Bake
• Roast
• Conv Roast
• Air Fry
• Pizza
• Proof
• Keep Warm
• Fast Preheat
• Dehydrate
Features
Technologies
• Air Fry Technology
• True Convection Technology
• True Convection Technology
Air Fry
Yes
Control Lock
Yes
Convection
Yes
Digital Temperature Display
Yes
Oven Light
Yes
Self-Cleaning
Yes
Additional Information
• Oven Control Features: Light on/ Off, Clock & Kitchen Timer, Time Cooking, Delay Start, Self clean, Control Lock Capability, Sabbath Mode, Temperature Probe C° or F° Programmable
• Power Cord Length: US - Not Included (Canada Included)
• Bake Element Power: 3,500W
• Broil Element Power: 3,500W
• Baking Sheet Size Fits: 29" x 16" Baking Sheet
• Power Cord Length: US - Not Included (Canada Included)
• Bake Element Power: 3,500W
• Broil Element Power: 3,500W
• Baking Sheet Size Fits: 29" x 16" Baking Sheet
Electrical Information
Information
• 3,000 W
• 50 A
• 240 V
• 60 Hz
• Plug Type: 50 Amp 4-Prong
• 50 A
• 240 V
• 60 Hz
• Plug Type: 50 Amp 4-Prong
Certifications and Approvals
Sabbath/Star-K
Yes
Accessories
Included
• 1 Standard Oven Rack
• 1 Telescopic Rack
• 1 Broiler Pan Set
• 1 Telescopic Rack
• 1 Broiler Pan Set
Dimensions
Class Width
36"
Width
35.87 inch(es) / 91.12 cm
Height
36 inch(es) / 91.44 cm
Depth (Including Handles)
29.75 inch(es) / 75.57 cm
Weight
231 lb(s) / 104.78 kg
Additional Dimensions
• Rubber Spacer Depth (Install On Back Panel): 3/4"
• Product Height (From Bottom To Top Of Back Splash): 36"
• Product Height (From Bottom To Top Of Side Panel): 36"
• Product Depth (From Back Panel To Handle): 29"
• Product Depth (From Back Panel To Bullnose): 27 1/2"
• Product Depth (From Back Panel To Control Panel): 26 3/8"
• Product Depth (From Back Panel To Side Panel Front): 24"
• Cutout Dimensions (WxDxH): 36" x 24 3/4" x 36" - 39"
• Adjustable Height: 3" Max
• Oven Internal Width: 29 3/4"
• Oven Internal Depth: 19 1/2"
• Oven Internal Height: 18"
• Product Height (From Bottom To Top Of Back Splash): 36"
• Product Height (From Bottom To Top Of Side Panel): 36"
• Product Depth (From Back Panel To Handle): 29"
• Product Depth (From Back Panel To Bullnose): 27 1/2"
• Product Depth (From Back Panel To Control Panel): 26 3/8"
• Product Depth (From Back Panel To Side Panel Front): 24"
• Cutout Dimensions (WxDxH): 36" x 24 3/4" x 36" - 39"
• Adjustable Height: 3" Max
• Oven Internal Width: 29 3/4"
• Oven Internal Depth: 19 1/2"
• Oven Internal Height: 18"
Shipping Dimensions
Width
39 inch(es) / 99.06 cm
Height
45.06 inch(es) / 114.45 cm
Depth
32 inch(es) / 81.28 cm
Weight
278 lb(s) / 126.1 kg
Warranty
Warranty
2 Years Parts and Labor
