Features
RADIANT BURNERS
Radiant burners use electric heating elements beneath a smooth, ceramic glass surface to deliver even and consistent heat.
WHITE PROJECTOR LIGHT ON PANEL.
The panel is illuminated by a white projector light, ensuring easy visibility and a modern look.
TRUE CONVECTION FAN.
For even heat distribution within the oven.
POWERFUL BROIL ELEMENT
The oven broiler features a 3,500 watts tube for quick and efficient broiling
Specifications
General
Series Name
Gordon Ramsay
Fuel Type
Electric
Installation Type
Freestanding
Color
Stainless Steel
Manufacturer Color
Stainless Steel with Blue Accent
Cooktop
Burners/Elements
5
Burners/Elements Output
• (1) Front Left Element 3,000 W (1,500 W &1,500 W)
• (2) Front Right Element 3,000 W (1,800W &1,200 W)
• (3) Rear Left Element 1,200 W
• (4) Rear Center Element 100 W
• (5) Rear Right Element 1,200 W
• (2) Front Right Element 3,000 W (1,800W &1,200 W)
• (3) Rear Left Element 1,200 W
• (4) Rear Center Element 100 W
• (5) Rear Right Element 1,200 W
Elements
Smoothtop
Oven
Capacity (cu. ft.)
6.0 cu. ft.
Number of Ovens
Single
Programs
• Bake
• Conv Bake
• Roast
• Conv Roast
• Air Fry
• Pizza
• Proof
• Keep Warm
• Fast Preheat
• Dehydrate
• Conv Bake
• Roast
• Conv Roast
• Air Fry
• Pizza
• Proof
• Keep Warm
• Fast Preheat
• Dehydrate
Features
Technologies
• Air Fry Technology
• True Convection Technology
• True Convection Technology
Air Fry
Yes
Control Lock
Yes
Convection
Yes
Digital Temperature Display
Yes
Oven Light
Yes
Self-Cleaning
Yes
Additional Information
• Oven Control Features: Light on/ Off, Clock & Kitchen Timer, Time Cooking, Delay Start, Self clean, Control Lock Capability, Sabbath Mode, Temperature Probe C° or F° Programmable
• Power Cord Length: US - Not Included (Canada Included)
• Bake Element Power: 3,500W
• Broil Element Power: 3,500W
• Baking Sheet Size Fits: 29" x 16" Baking Sheet
• Power Cord Length: US - Not Included (Canada Included)
• Bake Element Power: 3,500W
• Broil Element Power: 3,500W
• Baking Sheet Size Fits: 29" x 16" Baking Sheet
Electrical Information
Information
• 3,000 W
• 50 A
• 240 V
• 60 Hz
• Plug Type: 50 Amp 4-Prong
• 50 A
• 240 V
• 60 Hz
• Plug Type: 50 Amp 4-Prong
Certifications and Approvals
Sabbath/Star-K
Yes
Accessories
Included
• 1 Standard Oven Rack
• 1 Telescopic Rack
• 1 Broiler Pan Set
• 1 Telescopic Rack
• 1 Broiler Pan Set
Dimensions
Class Width
36"
Width
35.87 inch(es) / 91.12 cm
Height
36 inch(es) / 91.44 cm
Depth (Including Handles)
29.75 inch(es) / 75.57 cm
Weight
231 lb(s) / 104.78 kg
Additional Dimensions
• Rubber Spacer Depth (Install On Back Panel): 3/4"
• Product Height (From Bottom To Top Of Back Splash): 36"
• Product Height (From Bottom To Top Of Side Panel): 36"
• Product Depth (From Back Panel To Handle): 29"
• Product Depth (From Back Panel To Bullnose): 27 1/2"
• Product Depth (From Back Panel To Control Panel): 26 3/8"
• Product Depth (From Back Panel To Side Panel Front): 24"
• Cutout Dimensions (WxDxH): 36" x 24 3/4" x 36" - 39"
• Adjustable Height: 3" Max
• Oven Internal Width: 29 3/4"
• Oven Internal Depth: 19 1/2"
• Oven Internal Height: 18"
• Product Height (From Bottom To Top Of Back Splash): 36"
• Product Height (From Bottom To Top Of Side Panel): 36"
• Product Depth (From Back Panel To Handle): 29"
• Product Depth (From Back Panel To Bullnose): 27 1/2"
• Product Depth (From Back Panel To Control Panel): 26 3/8"
• Product Depth (From Back Panel To Side Panel Front): 24"
• Cutout Dimensions (WxDxH): 36" x 24 3/4" x 36" - 39"
• Adjustable Height: 3" Max
• Oven Internal Width: 29 3/4"
• Oven Internal Depth: 19 1/2"
• Oven Internal Height: 18"
Shipping Dimensions
Width
39 inch(es) / 99.06 cm
Height
45.06 inch(es) / 114.45 cm
Depth
32 inch(es) / 81.28 cm
Weight
278 lb(s) / 126.1 kg
Warranty
Warranty
2 Years Parts and Labor
