Features
RADIANT BURNERS
Radiant burners use electric heating elements beneath a smooth, ceramic glass surface to deliver even and consistent heat.
WHITE PROJECTOR LIGHT ON PANEL.
The panel is illuminated by a white projector light, ensuring easy visibility and a modern look.
TRUE CONVECTION FAN.
For even heat distribution within the oven.
POWERFUL BROIL ELEMENT
The oven broiler features a 3,500 watts tube for quick and efficient broiling
Specifications
General
Series Name
Gordon Ramsay
Fuel Type
Electric
Installation Type
Freestanding
Color
Black
Manufacturer Color
Black with Blue Accent
Cooktop
Burners/Elements
5
Burners/Elements Output
• (1) Front Left Burner 3,000W (1,500W &1,500W)
• (2) Front Right Burner 3,000W (1,800W &1,200W)
• (3) Rear Left Burner 1,200W
• (4) Rear Center Burner 100W
• (5) Rear Right Burner 1,200W
• (2) Front Right Burner 3,000W (1,800W &1,200W)
• (3) Rear Left Burner 1,200W
• (4) Rear Center Burner 100W
• (5) Rear Right Burner 1,200W
Elements
Smoothtop
Oven
Capacity (cu. ft.)
4.55 cu. ft.
Number of Ovens
Single
Programs
• Bake
• Conv Bake
• Roast
• Conv Roast
• Air Fry
• Pizza
• Proof
• Keep Warm
• Fast Preheat
• Dehydrate
• Conv Bake
• Roast
• Conv Roast
• Air Fry
• Pizza
• Proof
• Keep Warm
• Fast Preheat
• Dehydrate
Features
Technologies
• True Convection Technology
• Air Fry Technology
• Air Fry Technology
Air Fry
Yes
Convection
Yes
Digital Temperature Display
Yes
Oven Light
Yes
Self-Cleaning
Yes
Additional Information
• Bake Element Power: 3,000W
• Broil Element Power: 3,500W
• Baking Sheet Size Fits: 23" x 16" Baking Sheet
• Oven Control Features: Light on/ Off, Clock & Kitchen Timer, Time Cooking, Delay Start, Self clean, Control Lock Capability, Sabbath Mode, Temperature Probe C° or F° Programmable
• Broil Element Power: 3,500W
• Baking Sheet Size Fits: 23" x 16" Baking Sheet
• Oven Control Features: Light on/ Off, Clock & Kitchen Timer, Time Cooking, Delay Start, Self clean, Control Lock Capability, Sabbath Mode, Temperature Probe C° or F° Programmable
Electrical Information
Information
• 3,000 W
• 50 A
• 240 V
• 60 Hz
• Plug Type: 50 Amp 4-Prong
• Power Cord Length: US - Not Included (Canada Included)
• 50 A
• 240 V
• 60 Hz
• Plug Type: 50 Amp 4-Prong
• Power Cord Length: US - Not Included (Canada Included)
Certifications and Approvals
Sabbath/Star-K
Yes
Accessories
Included
• 1 Standard Oven Rack
• 1 Telescope Rack
• 1 Broiler Pan Set
• 1 Telescope Rack
• 1 Broiler Pan Set
Dimensions
Class Width
30"
Width
29.87 inch(es) / 75.88 cm
Height
14.17 inch(es) / 36 cm
Depth (Without Handles)
27.5 inch(es) / 69.85 cm
Depth (Including Handles)
29 inch(es) / 73.66 cm
Weight
201 lb(s) / 91.17 kg
Additional Dimensions
• Oven Internal Width: 29 3/4"
• Oven Internal Depth: 19 1/2"
• Oven Internal Height: 18"
• Rubber Spacer Depth (Install On Back Panel): 3/4"
• Product Height (From Bottom To Top Of Back Splash): 36"
• Product Height (From Bottom To Top Of Side Panel): 36"
• Cutout Dimensions (WxDxH): 30" x 24 3/4" x 36" - 39"
• Adjustable Height: 3" Max
• Product Depth (From Back Panel To Bullnose): 27 1/2"
• Product Depth (From Back Panel To Control Panel): 26 3/8"
• Product Depth (From Back Panel To Side Panel Front): 24"
• Oven Internal Depth: 19 1/2"
• Oven Internal Height: 18"
• Rubber Spacer Depth (Install On Back Panel): 3/4"
• Product Height (From Bottom To Top Of Back Splash): 36"
• Product Height (From Bottom To Top Of Side Panel): 36"
• Cutout Dimensions (WxDxH): 30" x 24 3/4" x 36" - 39"
• Adjustable Height: 3" Max
• Product Depth (From Back Panel To Bullnose): 27 1/2"
• Product Depth (From Back Panel To Control Panel): 26 3/8"
• Product Depth (From Back Panel To Side Panel Front): 24"
Shipping Dimensions
Width
32 inch(es) / 81.28 cm
Height
45.06 inch(es) / 114.45 cm
Depth
32 inch(es) / 81.28 cm
Weight
245 lb(s) / 111.13 kg
Warranty
Warranty
2 Years Parts and Labor
Documents
