Features
RADIANT BURNERS
Radiant burners use electric heating elements beneath a smooth, ceramic glass surface to deliver even and consistent heat.
WHITE PROJECTOR LIGHT ON PANEL.
The panel is illuminated by a white projector light, ensuring easy visibility and a modern look.
TRUE CONVECTION FAN.
For even heat distribution within the oven.
POWERFUL BROIL ELEMENT
The oven broiler features a 3,500 watts tube for quick and efficient broiling
Specifications
General
Series Name
Gordon Ramsay
Fuel Type
Electric
Installation Type
Freestanding
Color
Stainless Steel
Manufacturer Color
Stainless Steel with Black Accent
Cooktop
Burners/Elements
5
Burners/Elements Output
• (1) Front Left Burner 3,000W (1,500W &1,500W)
• (2) Front Right Burner 3,000W (1,800W &1,200W)
• (3) Rear Left Burner 1,200W
• (4) Rear Center Burner 100W
• (5) Rear Right Burner 1,200W
• (2) Front Right Burner 3,000W (1,800W &1,200W)
• (3) Rear Left Burner 1,200W
• (4) Rear Center Burner 100W
• (5) Rear Right Burner 1,200W
Elements
Smoothtop
Oven
Capacity (cu. ft.)
4.55 cu. ft.
Number of Ovens
Single
Programs
• Bake
• Conv Bake
• Roast
• Conv Roast
• Air Fry
• Pizza
• Proof
• Keep Warm
• Fast Preheat
• Dehydrate
• Conv Bake
• Roast
• Conv Roast
• Air Fry
• Pizza
• Proof
• Keep Warm
• Fast Preheat
• Dehydrate
Features
Technologies
• True Convection Technology
• Air Fry Technology
• Air Fry Technology
Air Fry
Yes
Convection
Yes
Digital Temperature Display
Yes
Oven Light
Yes
Self-Cleaning
Yes
Additional Information
• Bake Element Power: 3,000W
• Broil Element Power: 3,500W
• Baking Sheet Size Fits: 23" x 16" Baking Sheet
• Oven Control Features: Light on/ Off, Clock & Kitchen Timer, Time Cooking, Delay Start, Self clean, Control Lock Capability, Sabbath Mode, Temperature Probe C° or F° Programmable
• Broil Element Power: 3,500W
• Baking Sheet Size Fits: 23" x 16" Baking Sheet
• Oven Control Features: Light on/ Off, Clock & Kitchen Timer, Time Cooking, Delay Start, Self clean, Control Lock Capability, Sabbath Mode, Temperature Probe C° or F° Programmable
Electrical Information
Information
• 3,000 W
• 50 A
• 240 V
• 60 Hz
• Plug Type: 50 Amp 4-Prong
• Power Cord Length: US - Not Included (Canada Included)
• 50 A
• 240 V
• 60 Hz
• Plug Type: 50 Amp 4-Prong
• Power Cord Length: US - Not Included (Canada Included)
Certifications and Approvals
Sabbath/Star-K
Yes
Accessories
Included
• 1 Standard Oven Rack
• 1 Telescope Rack
• 1 Broiler Pan Set
• 1 Telescope Rack
• 1 Broiler Pan Set
Dimensions
Class Width
30"
Width
29.87 inch(es) / 75.88 cm
Height
14.17 inch(es) / 36 cm
Depth (Without Handles)
27.5 inch(es) / 69.85 cm
Depth (Including Handles)
29 inch(es) / 73.66 cm
Weight
201 lb(s) / 91.17 kg
Additional Dimensions
• Oven Internal Width: 29 3/4"
• Oven Internal Depth: 19 1/2"
• Oven Internal Height: 18"
• Rubber Spacer Depth (Install On Back Panel): 3/4"
• Product Height (From Bottom To Top Of Back Splash): 36"
• Product Height (From Bottom To Top Of Side Panel): 36"
• Cutout Dimensions (WxDxH): 30" x 24 3/4" x 36" - 39"
• Adjustable Height: 3" Max
• Product Depth (From Back Panel To Bullnose): 27 1/2"
• Product Depth (From Back Panel To Control Panel): 26 3/8"
• Product Depth (From Back Panel To Side Panel Front): 24"
• Oven Internal Depth: 19 1/2"
• Oven Internal Height: 18"
• Rubber Spacer Depth (Install On Back Panel): 3/4"
• Product Height (From Bottom To Top Of Back Splash): 36"
• Product Height (From Bottom To Top Of Side Panel): 36"
• Cutout Dimensions (WxDxH): 30" x 24 3/4" x 36" - 39"
• Adjustable Height: 3" Max
• Product Depth (From Back Panel To Bullnose): 27 1/2"
• Product Depth (From Back Panel To Control Panel): 26 3/8"
• Product Depth (From Back Panel To Side Panel Front): 24"
Shipping Dimensions
Width
32 inch(es) / 81.28 cm
Height
45.06 inch(es) / 114.45 cm
Depth
32 inch(es) / 81.28 cm
Weight
245 lb(s) / 111.13 kg
Warranty
Warranty
2 Years Parts and Labor
