Features
DIGITAL CONTROL CENTER
Adjusting the temperature setting on the Digital Control Center Board sets the speed of the feed, thus the
temperature output. This control is fully adjustable, from hot smoke 170°F to 600°F searing and shows both
“Desired” and “Actual” grill and meat probe temperature readings.
AUGER FEED SYSTEM
The heart of the feed system is a time proven, metal auger and high torque auger motor. This combination allows for different quality of pellet fuels to be used while reducing the possibilities of “jams” taking place. The metal auger design also helps in maintaining a constant and even feed of the fuel to the fire, resulting in better and consistent temperature control.
PORCELAIN COATED
Porcelain coated cast iron main cooking rack and removable upper cooking rack
ELECTRIC IGNITER
Electric Igniter eliminates the need for matches & starter fluids.
Additional Features
PRIMER BUTTON
Primer Button aids in quicker heat recovery or increasing smoke intensity.
BURN GRATE
The burn grate is constructed out of stainless steel and is the heart of the grill. The burning temperature in the grate can reach temperatures of 1700 to 2000°F. The air holes are designed to allow the right combination of fan forced air to force the wood pellets to burn hot and clean while grilling or allow them to smolder and produce the savory smoke while in the smoke temperature. The back of the burn grate has a large oblong hole in the back to allow the hot igniter air to come through, causing the pellets to catch fire.
LONG TERM EFFICIENCY
This LG Smoker Grill can run efficiently over extended periods of time and at different heat output levels, as long as the fuel supply is dry, uninterrupted and timely cleaning and maintenance is performed.
Specifications
General
Series Name
LG
Style
Special Design
Type
Cart
Color
Black
Power Source
Wood Pellets
Power
48 000 BTU's
Cooking Surface
• 913 Square Inches Total Cooking Surface
• Burger Capacity: 57 square inches
• Main Level: 633 Square Inches
• Upper Level: 280 Square Inches
• Burger Capacity: 57 square inches
• Main Level: 633 Square Inches
• Upper Level: 280 Square Inches
Features
Additional Information
• Digital Control Center - Oven Board
• Full Function Programmable Meat Probe
• 180F to 600F Temp Range (*5 degree increments)
• Porcelain Coated Cast Iron Main Cooking Rack
• Porcelain Steel Removable Upper Cooking Rack
• Indirect/Direct Flame Cooking with Standard Flame broiler
• Full Stainless Steel Burn Grate
• Fan Forced Convection Cooking
• 300 Watt Auto Igniter
• Proprietary Exhaust System for even smoking
• Automatic Start Up and Cool Down
• Power Source: 120 Volt 50/60hz 3.1 amp 3 prong electrical appliance
• Heavy Duty 14 Gauge Steel Construction
• Heavy Duty Casters and Wheels
• High Temp Powder Coat Finish
• 14 lb Hopper Capacity
• Large Stainless Steel Stay Cool Vented Handle
• Solid Bottom Shelf
• Dome Thermometer with Bezel
• Full Function Programmable Meat Probe
• 180F to 600F Temp Range (*5 degree increments)
• Porcelain Coated Cast Iron Main Cooking Rack
• Porcelain Steel Removable Upper Cooking Rack
• Indirect/Direct Flame Cooking with Standard Flame broiler
• Full Stainless Steel Burn Grate
• Fan Forced Convection Cooking
• 300 Watt Auto Igniter
• Proprietary Exhaust System for even smoking
• Automatic Start Up and Cool Down
• Power Source: 120 Volt 50/60hz 3.1 amp 3 prong electrical appliance
• Heavy Duty 14 Gauge Steel Construction
• Heavy Duty Casters and Wheels
• High Temp Powder Coat Finish
• 14 lb Hopper Capacity
• Large Stainless Steel Stay Cool Vented Handle
• Solid Bottom Shelf
• Dome Thermometer with Bezel
Dimensions
Width
45.75 inch(es) / 116.21 cm
Height
43.75 inch(es) / 111.13 cm
Depth
24 inch(es) / 60.96 cm
Weight
161 lb(s) / 73.03 kg
Shipping Dimensions
Weight
178 lb(s) / 80.74 kg
Warranty
Warranty
The "LG SERIES Smoker" wood pellet barbecue line, manufactured by Dansons Inc., carries a five (5) year limited warranty from the date of sale to the original owner only, against defects and workmanship on all steel parts, (excluding the burn grate), and three (3) years on electrical components. There is NO specific warranty on grill probe, meat probe, the paint, powder coat, burn grate, grill cover and all gaskets or against damage caused from corrosion.
UPC
UPC#
684678080610
