Specifications
General
Fuel Type
Electric
Installation Type
Slide-in
Color
Stainless Steel
Manufacturer Color
Smudge resistant stainless steel
Appliance Care
EasyClean®
Cooktop
Burners/Elements
4
Burners/Elements Output
• Left Rear: 1200W
• Right Rear: 1200W
• Left Front: 3200W (UltraHeat™)
• Right Front: 3200W (UltraHeat™)
• Center (Warming Zone)
• Right Rear: 1200W
• Left Front: 3200W (UltraHeat™)
• Right Front: 3200W (UltraHeat™)
• Center (Warming Zone)
Burner/Element Size
• Left Rear: 6" Single
• Right Rear: 6" Single
• Left Front: 9" / 6" Dual
• Right Front: 9" / 6" Dual
• Center (Warming Zone)
• Right Rear: 6" Single
• Left Front: 9" / 6" Dual
• Right Front: 9" / 6" Dual
• Center (Warming Zone)
Elements
Smoothtop
Oven
Capacity (cu. ft.)
6.3
Number of Ovens
Single
Programs
Warm, Bake, Broil, EasyClean
Features
Technologies
• UltraHeat™ Elements
• GoCook Smart Oven Light
• WideView™ Window Oven Door
• GoCook Smart Oven Light
• WideView™ Window Oven Door
Oven Light
Yes
Additional Information
• Cooktop type: Radiant, Ceramic Glass
• Cooktop Finish: Black Ceramic Glass with Gray Pattern
• Hot Surface LED Indicator
• Broil Element (Watt): 2600W
• Oven Bake Element Wattage: 2200W
• Oven Racks: 2 Standard
• No. of Rack Positions: 7
• Control Type: Knob
• Temperature Unit of Measure: Fahrenheit
• Cooktop Finish: Black Ceramic Glass with Gray Pattern
• Hot Surface LED Indicator
• Broil Element (Watt): 2600W
• Oven Bake Element Wattage: 2200W
• Oven Racks: 2 Standard
• No. of Rack Positions: 7
• Control Type: Knob
• Temperature Unit of Measure: Fahrenheit
Electrical Information
Information
• Amp rating at 208V: 41.3A
• Amp rating at 240V: 47.7A
• KW rating at 208V: 8.6kW
• KW rating at 240V: 11.5kW
• Required power supply amp: 40A
• Amp rating at 240V: 47.7A
• KW rating at 208V: 8.6kW
• KW rating at 240V: 11.5kW
• Required power supply amp: 40A
Certifications and Approvals
ADA Compliant
Yes
Accessories
Included
2 Standard Racks, Rear Filler Kit, Anti-tip Kit
Optional
Slide-in Range Filler Kit (Side Gaps): LSFL301S
Dimensions
Class Width
30"
Width
29.87 inch(es) / 75.88 cm
Height
37.25 inch(es) / 94.62 cm
Depth (Including Handles)
29.22 inch(es) / 74.22 cm
Additional Dimensions
• Product Height to Cooking Surface: 36"
• Overall Depth (in.) - with handle: 30"
• Cutout Dimensions (W x H x D): 30" x 36" x 25"
• Overall Depth (in.) - with handle: 30"
• Cutout Dimensions (W x H x D): 30" x 36" x 25"
Shipping Dimensions
Width
32.5 inch(es) / 82.55 cm
Height
44 inch(es) / 111.76 cm
Depth
30.5 inch(es) / 77.47 cm
Weight
162 lb(s) / 73.48 kg
Warranty
Warranty
1-Year Parts and Labor
UPC
UPC#
048231346245
