Features
FIT GUARANTEE
Replace your old 30” free-standing range with a new 30" slide-in model. GE slide-in ranges are guaranteed for an exact fit to make replacement easy.
12"/9" DUAL ELEMENT
A power boiler produces concentrated heat for rapid boiling in a flexible 12-inch/9-inch burner size, so you spend less time waiting and more time cooking
FAST PREHEAT
Make hot meals in a hurry with less time preheating.
TRUE EUROPEAN CONVECTION WITH PRECISE AIR
Bakes evenly as warm air blows from the top in and around bakeware.
STEAM CLEAN
Fill the resevoir with water and set your oven to "Steam Clean". After 30 minutes you're able to wipe clean all grime and residue.
Additional Features
WARNING ZONE (FIFTH ELEMENT WARMING ZONE)
Simplify meals by keeping foods fresh from the oven warm and ready to serve.
HIDDEN BAKE ELEMENT
Hides previously exposed bottom element to deliver a clean interior appearance
GLASS TOUCH CONTROLS
Features the smooth glass design that is easy-to-operate and easy-to-clean
Specifications
General
Fuel Type
Electric
Installation Type
Slide-in
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Appliance Care
Steam Clean
Cooktop
Burners/Elements
5
Burners/Elements Output
• Left Front Power Boil Element: 3100 W
• Left Rear Element: 1200 W
• Right Front Element: 3000 W
• Right Rear Element: 1200 W
• Center Element Warming Zone: 100 W
• Left Rear Element: 1200 W
• Right Front Element: 3000 W
• Right Rear Element: 1200 W
• Center Element Warming Zone: 100 W
Burner/Element Size
• Left Front Power Boil Element: 9"/6"
• Left Rear Element: 6"
• Right Front Element: 12"/9"
• Right Rear Element: 6"
• Center Element Warming Zone: 6"
• Left Rear Element: 6"
• Right Front Element: 12"/9"
• Right Rear Element: 6"
• Center Element Warming Zone: 6"
Elements
Smoothtop
Oven
Capacity (cu. ft.)
• Total Capacity: 6.6 cu.ft.
• Upper Oven: 2.2 cu.ft.
• Lower Oven: 4.4 cu.ft.
• Upper Oven: 2.2 cu.ft.
• Lower Oven: 4.4 cu.ft.
Number of Ovens
Double
Programs
• Convection Bake
• Delay Bake Option (Time Bake)
• Fast Preheat
• Hi / Low Broil
• Melt Setting
• Delay Bake Option (Time Bake)
• Fast Preheat
• Hi / Low Broil
• Melt Setting
Features
Technologies
True European Convection with Precise Air
Control Lock
Yes
Convection
Yes
Delay Bake/Start
Yes
Digital Temperature Display
Yes
Oven Light
Yes
Additional Information
• Audible Preheat Signal
• Auto Oven Shut-Off with Override
• Auto Recipe Conversion
• Electronic Clock and Kitchen Timer
• Oven "ON" Light
• 1 Heating Element "ON" Indicator Light
• 4-Pass Bake Element
• 8-Pass Broil Element
• Hidden Bake
• 3 Oven Racks
• 6 Rack Positions
• Bake: 2650 W
• Broiler: 3600 W
• Convection: 1500 W
• 1 Halogen Light
• Auto Oven Shut-Off with Override
• Auto Recipe Conversion
• Electronic Clock and Kitchen Timer
• Oven "ON" Light
• 1 Heating Element "ON" Indicator Light
• 4-Pass Bake Element
• 8-Pass Broil Element
• Hidden Bake
• 3 Oven Racks
• 6 Rack Positions
• Bake: 2650 W
• Broiler: 3600 W
• Convection: 1500 W
• 1 Halogen Light
Electrical Information
Information
• 240 V /208 V
• 60 Hz
• 40 A
• 60 Hz
• 40 A
Certifications and Approvals
ADA Compliant
Yes
Sabbath/Star-K
Yes
Accessories
Optional
Trim Kit JXFILLR1BB
Dimensions
Class Width
30"
Width
29.87 inch(es) / 75.88 cm
Height
36.5 inch(es) / 92.71 cm
Depth (Without Handles)
25.75 inch(es) / 65.40 cm
Depth (Including Handles)
28.25 inch(es) / 71.76 cm
Weight
170 lb(s) / 77.11 kg
Additional Dimensions
Oven Interior Dimensions (W x H x D): 24-1/8" x 19-1/2" x 19-3/8"
Shipping Dimensions
Width
32 inch(es) / 81.28 cm
Height
44.8 inch(es) / 113.79 cm
Depth
30.9 inch(es) / 78.49 cm
Weight
191.01 lb(s) / 86.64 kg
Warranty
Warranty
Limited 1 Year Parts and Labor
UPC
UPC#
084691855552
