Features
THREE SPEED VENTILATION FAN
Quickly move odors and steam away from the cooktop's surface with three levels of ventilation that recirculate air up to 340 cubic feet per minute (CFM).
LED LIGHTING
Get a clearer view of your cooktop with two LED lights that illuminate the cooking surface.
CHARCOAL FILTER
Enjoy fresher air with the replaceable carbon charcoal recirculation filter, which captures odors and helps filter recirculated air from the exhaust fan.
DISHWASHER SAFE GREASE FILTER
Easy to remove, dishwasher safe aluminum mesh filters help trap particles and helps reduce odors.
PUSH BUTTON CONTROLS
Easily select fan speed or lighting level with simple push button controls.
Specifications
General
Airflow
350 CFM
Style
Chimney
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Installation
Wall Mount
Features
Dishwasher-Proof Filters
Yes
Ducting Information
Duct Diameter: 6"
Speeds
• Exhaust Fan Speeds: 3
• Maximum Air Flow Capacity: 350 CFM
• Maximum Air Flow Capacity: 350 CFM
Additional Information
• Glass Canopy Hood
• Ductless Vent
• Maximum Sones Rating: 5.5 sone
• Minimum Sones Rating: 3.0 sone
• Charcoal Filter Quantity: 2
• Lighting Type: LED
• Number of Lights: 2
• Control Type: Mechanical
• Ductless Vent
• Maximum Sones Rating: 5.5 sone
• Minimum Sones Rating: 3.0 sone
• Charcoal Filter Quantity: 2
• Lighting Type: LED
• Number of Lights: 2
• Control Type: Mechanical
Electrical Information
Information
Voltage Rating: 120 V
Certifications and Approvals
Information
ETL
Accessories
Included
• Grease Filter
• Charcoal Filter
• Charcoal Filter
Optional
Optional 10 Ft. Chimney Extension
Dimensions
Class Width
36"
Width
35.34 inch(es) / 89.77 cm
Height
30 inch(es) / 76.2 cm
Depth
17.72 inch(es) / 45.01 cm
Weight
52.01 lb(s) / 23.59 kg
Additional Dimensions
Height With Flue Extension: 45"
Warranty
Warranty
1-Year parts and labor
